TM-3013 AC/DC Clamp Meter

Product Price $ 200
count:

TM-3013 AC/DC Clamp Meter-Require

TM-3013 AC/DC Clamp Meter

TM-3013 AC/DC Clamp Meter

CAT IV 600V, CAT III 1000V

3-3/4 digit LCD Backlit display with maximum reading of 4000.

Analog Bargraph.

AC voltage range: 0 to 750V.

AC current range: 0 to 1200A.

DC voltage range: 0 to 1000V.

DC current range: 0 to 1200A

Peak Hold, Data Hold, Min/Max.

Test Ranges: ACV, ACA, DCV, DCA, Resistance, Frequency, Diode, Continuity.

Work Light.

Auto Power Off.

Double injection outer case.

Specification

Model

TM-3013

Max measuring current

1200A

Display counts

4000

Overvoltage category

CAT IV 600V CAT III 1000V

Max conductor size

52mm

AC current

0.1~1200A

DC current

0.1~1200A

AC voltage

0.001~750V

DC voltage

0.001~1000V

Resistance

0.1~4000Ω

Continuity buzzer

V

Diode

Test voltage<3.3V

Capacitance

-

Frequency

1~100KHz

ADP Measurement

-

Analogue Bargraph

V

TRMS

-

Backlit

V

Work light

V

Autorange

V

Auto power OFF

V

Peak hold

V

Inrush

-

Data hold

V

MAX/MIN

V

DCA zero

V(REL)

Dimension

266x93x47mm
